Current output type (4 -20) mA: Sensor installation: connect the amplifier to the turbine flow sensor. This incremental output is digital in form, and as such, can be totalized with a maximum error of one pulse regardless of the volume measured. Using EEPROM technology can store the cumulative total and the instrument system. Wiring: (4-20) mA output type amplifier external leads (such as red wire and white wire).

Current output: (4-20)mA external +24V power supply DC (two-wire system). Measures Flow Rates As Low As 0.03 GPM, 0.11 LPM Splash-Proof All Plastic Construction for Superior Chemical and Corrosion Resistance. These materials help the meter to maintain accuracy and mechanical integrity when measuring the corrosive and abrasive fluids found in many industries. ), ( How a Current to Pressure Transducer Works, Common Symbols Used in Process and Instrumentation Diagrams, How to Measure Electric Motor Insulation Resistance, How to Test 3-phase AC Motor Windings with an Ohmeter, How to Read Torque Speed Characteristics of AC Motors, Instrument Abbreviations Used in Instrumentation Diagrams, How to Convert Thermocouple Milivolts to Temperature, Principles & Formulas for Flow Measurement. Compact sizeMeasurement in any meter orientationOperating pressure up to 362.50 psi (25 bar)Temperature range of 4212 F (20100 C)Accuracy of 3%Resolution up to 83,000 ppg (22,000 ppl), depending on the model. ), ( ), ( Turbine flowmeters produce output signals that are electronic pulses but other output signals analog(4 20mA), visual or digital- are available.



Working voltage: external power supply +24VDC (generally a two-wire system) Simple and firm structure easy for installation and dismantling. The induced signals, after being amplified and rectified will form a continuous rectangular impulse wave with certain amplitude which may be remotely transmitted to a display instrument indicating the instant flow and the cumulative flow of fluid.

} ), (

Turbine flow meters are designed to maximize throughout and minimize pressure drop, maintain high flow rates over an extended flow range and offer pulse output that is linear to the flow rate. Masterflex is now part of Avantor See press release >.

Display units offer you the selection of rate, total, reset of the total, programmable sleep mode, and real-time clock done via magnet wand provided on display when cover cannot be removed (such as in an explosion proof area like an oil platform), or via buttons on display for non-explosion proof models. One-stop supplier of industries meters and solution provider. (4) Measurement of non-conductive liquids. Analog signal output

The angular (rotational) velocity of the turbine rotor is directly proportional to the fluid velocity flowing through the turbine. Micro-Flow Polypropylene Sensors For Low Flow Applications.

Options compatible with previous selections will be in bold.

bvseo-msg: The resource to the URL or file is currently unavailable.. The resulting output is taken by an electrical pickoff(s) mounted on the meter body. ), ( ), (

(3) At least 15 diameters upstream and 5 diameters downstream of straight pipe is.

The rotation of turbine rotor generates electrical pulses in the pick off attached to flow meter housing.

Turbine flowmeters are applicable to clean fluids over a pressure range from sub-atmospheric to over 6,000psi and temperatures from -450 to about 6000 degree Fahrenheit.

All Rights Reserved.

-General working voltage: +12VDC or +24VDC two kinds (the power supply must be selected before ordering). No.9-1 Haifu Road Dalian Bonded Area Pilot Free Trade Zone Liaoning China 116001, The premier global supplier and export of exceptional instruments and industry products, When it comes to Instrumentation, we are the one you need! (5) Capability of heating measuring device. 11 15 The repeatability of the meters ensures quality measurement over a wide range of flow rates, temperatures, compositions and viscosities. The meters are often installed for measurement during crude oil production, tank farm/storage inventory control, floating production, storage and off-loading (FPSO) as well as refined product loading and offloading. From the graph, the minimum flow that will guarantee a linearity of -0.25 or +0.25 is 100litres/min.

The transmission cable is required to be at the end of the display instrument.

The rimmed rotor improves pulse resolution, particularly in DN150 (6-in) and larger line size meters.

(>510-6m2/s, the flow meter should be calibrated in real liquid before use, IP65(IP67, IP68 optional, pulse converter probe IP00), No display: Herssman jointpulse output (24 VDC power supply), No displayHerssman joint 4-20mA output (24 VDC power supply), No display:pulse output (24 VDC power supply), No display:4-20mA output (24 VDC power supply), LCDdisplay:Nooutput (3.6V lithium battery supply), LCDdisplay: pulse output ( 24 VDC power supply), LCDdisplay: 4-20mA output (24 VDC power supply), LCDdisplay: pulse output(3.6V lithium batteryand24 VDC powersupply), LCDdisplay: 4-20mA output(3.6V lithium batteryand24 VDC powersupply). Edit these specs to order a different model. ), Learning Instrumentation And Control Engineering, Industrial Motor Starters and Starting Methods, Electrical Protection of 3 phase Motors: Types and Protection Schemes, Understanding the Technical Specifications on the Nameplate of Solar Panels, A Guide to Solar Panels Power Installations, How to Specify Electric Motors for Hazardous Locations, Understanding Battery Technical Specifications, Instrumentation Books for Instrument Engineers and Technicians, Sizing Orifice Plates with Daniel Flow Calculator. Under certain conditions, the rotation speed of the blade will be in direct proportion to the flow velocity. Sign up to receive the latest in industry news, products, & services. Display six-digit instantaneous flow and ten-digit cumulative total.

Compliant with the ASME Bioprocessing Equipment Standard BPE-201911 Sizes Available, from to 3"Flow Rates from 0.35 to 650 GPMSuitable For Cleaning Out Of Place (COP)NIST Certificate Standard. (3) On-site display type When 1000mV5000mV, d=2.0.

Please contact us if you need assistance purchasing this product in another country. 2022 Emerson Electric Co. All rights reserved. 5 }, Failed to Save Configurations, Click on Configure Button Start Again. ), (

Please select a different combination.

Rely on our worldwide service network for expert support, 24/7/365.

The effective value of the output voltage of the coil, mV; d is the coefficient, m/mV.

The blade will rotate as the friction moment and the fluid resistance are overcome, and it will reach a stable speed when the moments are at balance.

(4) Signal transmission line requirements (1) Not suitable for high viscous fluids. The turbine meters also minimize fiscal measurement uncertainty by delivering high-frequency pulse resolution to account for minute increments of the flow rate. Phase Ii Flat No A -202 Shivtirthnagar Paud Road Kanchanban Society S No 109/1 3 Kothrud Pune - 411038, Maharashtra, India, Phase Ii Flat No A -202 Shivtirthnagar Paud Road Kanchanban Society S No 109/1 3 Kothrud.

*Highlighted options are not compatible.

Turbine flowmeters are engineered to accurately measure the flow of liquids and gases in pipes.

304SS Liquid Turbine Flow Meter, Pulse Output. 1% of Actual Flow Accuracy Includes 3-point NIST certificate Pressure Rating Up to 345 bar (5000 psi) Stainless Steel Construction Economical Easy Maintenance Design. Small signal removal function.

Copyright 1996-2022 IndiaMART InterMESH Ltd. All rights reserved.

Product(s) in your cart may not be available in the selected country and will be removed from your cart if you choose the SELECT button below. Signal transmission distance: less than 250m. You message has been sent! Process Control for Power & Water Industries, SCADA, Remote Terminal Units (RTU) & Flow Computers, Programmable Automation Control Systems (PLC/PAC), AVENTICS Product Calculation Pneumatics, Integrated Solutions for Air Conditioning, Commercial Space Heating Scroll Compressors, Residential Space Heating Scroll Compressors, Click to view our Accessibility Policy and contact us with accessibility-related issues, Residential Construction & Home Improvement. The sensor is of hard alloy bearing thrust type, which mayguarantee the precision and improve the wear resistance performance as well.

Note: Please be sure to complete all wiring and check whether the wiring is correct before turning on the power. The signal transmission line should be shielded cable to prevent inductive noise from outside. (2) Temperature range of fluid measurement: -450 to +6000 degree Fahrenheit.

Sanitary Turbine Flow Meters w/ Tri-Clamp Connection. The first line displays the instantaneous flow rate, and the second line displays the cumulative value.



Installation: After the turbine flow sensor is installed, screw the amplifier to the connector of the full-wheel flow sensor.



The transmission cable should not be close to the strong electromagnetic equipment, and it is not allowed to be arranged in parallel with the power line. Quickly access contact information for your area representative. Offer meter-mounted display, pulse, or 4 to 20 mA output versions. Pleasecontact usfor assistance. Therefore, various electrical interference phenomena should be prevented during installation, namely electromagnetic induction, electrostatic and capacitive coupling. Flow rates below this will plunge the turbine meter into non-linearity. They measure flow on a volumetric basis. The basic meter consists of a freely suspended bladed rotor positioned axially in the flow stream with the flowing fluid pushing against the blades. Turbine flow sensor heart is high accurate and balanced turbine rotor and pickup coil, mehaniccal energy ( velocity) of fluid passing through the flow meter rotate a rotor, an angular velocity of rotor proportional to fluid flow rate (mechanical energy /velocity) in the flow path ,through pickup coil generate electrical frequency proportional to angular velocity of turbine rotor, and flow rate of fluid,Turbine flow sensor output is direct pick up coil / amplified pulse/ linear current or voltage. Turbine flow sensor heart is high accurate and balanced turbine rotor and pickup coil, mehaniccal energy ( velocity) of fluid passing through the flow meter rotate a rotor, an angular velocity of rotor proportional to fluid flow rate (mechanical energy /velocity) in the flow path ,through pickup coil generate electrical frequency proportional to angular velocity of turbine rotor, and flow rate of fluid, Enclosure : S.S-304/S.S-316, Shaft : Hard Stainless Steel-316 with, Accuracy : +/- 0.5 or 1% FSD, Fluid &Ambient temperature: -20 to 120 Deg. .product-calibration-tag a{padding-left: 0px !important; background: none !important;}div#sfdcChatStart,.helpButton{display: none;}/* Reduce font on cart page for CA only */ html[lang="en-CA"] .cart-header .cart-overview, html[lang="fr-CA"] .cart-header .cart-overview{font-size: 10.5px;}@media screen and (min-width: 1024px){.product__list--wrapper h1.results.hidden-xs.hidden-sm{margin: 0 auto; width: 98.5%; padding: 0 0 10px;}}@media screen and (max-width: 1024px) and (min-width: 1366px){.product__list--wrapper h1.results.hidden-xs.hidden-sm{margin: 0 auto; width: 98.8%; padding: 0 0 10px;}}/* mini-cart dropdown on mobile */.mini-cart-modal{right: 0px;width: 368px;} @media screen and (max-width: 1024px) and (min-width: 769px){.page-articleDetailsPage .product__list--wrapper .pagination-bar.top .pagination-toolbar{width: 100%;}}@media only screen and (max-width: 640px){.page-articleDetailsPage .product__list--wrapper .pagination-bar.top .pagination-toolbar{width: inherit;}}.seo-widgets.related-products .wrapper .product.desc {font-size: 13px;line-height: 16px;letter-spacing: 0.16px;color: #696969;padding: 0px;margin-top: 12px;}.seo-widgets.related-products .wrapper .product.desc a {height: 32px;overflow: hidden;text-overflow: ellipsis;display: box;display: -webkit-box;display: -ms-box;display: -moz-box;line-clamp: 2;-webkit-line-clamp: 2;-webkit-box-orient: vertical;}/* Hide chat button on solutions page */.solutions-banner-container .chatBtn {display: none;}.incredible-expertise .incredible-expertise-left .image-container .image img{height: auto;}.one-third-two-third-container .right-section .tab-content .content-card .article-content{margin: 0 auto 0 0}a.sub-level-link.dropdown-item[href*="/resources/industry/spectris-companies"] {

Turbine flow sensor model no wise Technical data: Model no Line size Range, BT-DTFS-004 04 mm 40~400 L/H, BT-DTFS-012 12 mm 600~6000 L/H, BT-DTFS-025 25 mm 1000~10000 L/H, BT-DTFS-040 40 mm 2000~20000 L/H, BT-DTFS-050 50 mm 4000~40000 L/H, BT-DTFS-080 80 mm 10000~100000 L/H, BT-DTFS-100 100 mm 20000~200000 L/H, BT-DTFS-150 150 mm 30000~300000 L/H, BT-DTFS-200 200 mm 80000~800000 L/H, Fuel Consumption Meter | Diesel Flow Sensor, Oval Gear Positive Displacement Flow Meter, sight glass flow indicator with Liquid flow sensor, Helical Rotor Positive Displacement Flow meter, Plastic Helical Rotor Flow Sensor and Meter, Turbine Flow Meter - Full Stainless Steel, Electromagnetic flow meter / BTU/Heat/Energy flow meter, Smart battery operated electromagnetic flow meter with inbuilt GPRS, Vortex flow meter - IBR approved Steam Flow Meter, Inteligent Flow Rate Totalizer - Mass, Volume, Steam, BTU, Hydrostatic level transmitter - vented and non vented.



Small loss of pressure fine repeat ability and high precision.

When liquid flows through the casing of the sensor, the impulse of fluid will provide the blade with a rotation moment as there is an angle between the blade of the impeller and the flow direction. Type of output signal: square wave signal. The output pulses are amplified & converted to measure flow rate & Integration. Our reliability services are key to avoiding unplanned shutdowns, increasing yield and reducing costs. 2



overflow:hidden; Signal output: pulse output: (0 -5000) Hz (adjustable) external +24V power supply DC; Masterflex Single-Use Systems and Assemblies, AW-Lake Turbine Flowmeter 1/2" 0.9-9.0 GPM -pulse output, Turbine Flowmeter 1/2" 0.9-9.0 GPM -pulse output, You have successfully subscribed to our newsletter, Add more products on the full Quick Order page, Gear and Positive Displacement Flowmeters, Masterflex Pump Head Roller Material Compatibility, MasterSelect Pump Configurator and Selection Tool, Fluid temperature of -150 to 450F (-101 to 232C), Meters with display show flow rate, total, and real-time clock.

We will be in touch soon. SIN-LWGY series liquid turbine flowmeter is a kind of speed instrument, which has the advantages of high accuracy, good repeatability, simple structure, small pressure loss and convenient maintenance.

Call or Email us and we will make sure you get the right product or part for the job.

(2) The output frequency of the pickoff is proportional to the flow rate. 2022 Masterflex, LLC. @media screen and (max-width:1024px){ Do not reverse the connection, otherwise, the amplifier board may be easily damaged. As fluid flows through the meter, it impinges upon turbine blades that are free to rotate about an axis along the center line of the turbine housing. Wiring: The pulse output amplifier has three external leads, such as red wire, white wire, and a shield. Please enable JavaScript to use this website. Our Global Service Centers support all your service requirements or technical queries.

22 ), (

Tighten the lock nut after reaching the bottom. 7 304 SS Turbine Flow Meters With 37 Flare. Its value can be taken: when V<100mV, d=1.0; Proven, cost-effective technology that offers highly reliable, repeatable measurement with minimal maintenance required.

Emerson is where technology and engineering come together to create solutions for the benefit of our customers, driven without compromise for a world in action.

9

1 (1) Digital signal output The output of the turbine flowmeter is a pulse digital signal proportional to the flow rate. .top-level { The meter features a 304 stainless steel housing and rotor support, CD4MCU stainless steel rotor, and abrasion-resistant tungsten carbide rotor shaft and 316SS bearings. Output signal: (4-20)mA or (1~5)V, 4mA corresponds to zero flow of turbine flow sensor, 20mA corresponds

19 Download our informative tech guide to increase your liquid turbine meter IQ.



32 }. The shield is grounded.

A liquid turbine meter is used for volumetric total flow and/or flow rate measurement and has a relatively simple theory of operation. 12

The meters are rugged, reliable & precise instruments suitable for all Industrial Chemicals, Fuels etc.

Signal transmission distance: less than 250m. ), ( The advantages are easy to accumulate and easy to send into the computer system.

All Rights Reserved. Flow impinging upon the blade causes the rotor to spin at an angular velocity that is proportional to the flow rate. Limit the maximum length of the signal line. Powered by, (

C, high electric level : High than 8 VDC( input voltage 12 VDC), low electric level : lower than 0.8 VDC( input voltage 12 VDC). 1/2" Turbine Flow Meter, 304SS, Pulse Output, 6.6 GPM, Temperature Connectors, Panels and Block Assemblies, Temperature and Humidity and Dew Point Meters. (7) Specifications critical for measuring range and viscosity, 2009 - 2022 instrumentationtoolbox.com.

The rotational speed of the turbine is proportional to the velocity of the fluid & hence truly represents the volume of the fluid flowingbreitling replicathrough meter. 10 The FTB-900 Series Turbine Flow Meters are designed to meet the demands of the most rigorous flow measurement applications. The FTB-900 Series is a low cost Liquid Turbine Flow Meter with an amplified square wave pulse output available in 12 sizes covering flow ranges between 0.176 to 880 GPM. By selecting a new country/region, product(s) may be unavailable and items in your shopping cart will be removed. These turbine flowmeters are designed with only one moving part for easy cleaning. Let us help you find the right solution for your measurement needs. Our performance services offer expertise and support to help take your operation to the next level. (3) Very high-pressure capability: 6,000psi. Errors were found with the address you provided.

The maximum length of the signal line is L=dV, where V is the sensor at the minimum flow After the turbine flow sensor is installed, put the amplifier Screw it to the turbine flow sensor, and tighten the lock nut after the amplifier reaches the end. Turbine meters are simple to operate and maintain, and in service worldwide as a reliable, cost-effective method for achieving accurate flow measurement. Dedicated to the success of your entire fluid path from research to production since 1955. (1) High accuracy, repeatability and Rangeability for a defined viscosity and.

display: none !important;

Within a certain range of flow, the impulse frequency f is in direct proportion to the instant flow of fluid flowing through the sensor. Due to the magnetic conductivity of the blade, when located in the magnetic field generated by the signal detector (made of permanent magnet steel and coils), the rotating blade will cut the magnetic lines and periodically change the flux through the coil, thereby inducing electrical impulse signals at both ends of the coil.

When powering the line, you must pay attention to the following points: Output signal amplitude: + 12VDC power supply amplitude is about 10V,+24VDC power supply amplitude is about 20V. A major advantage of the turbine meter is that each electrical pulse is also proportional to a small incremental volume of flow.

Quickly size a turbine meter to your application with our easy-to-use tool. Please verify your address. ), (
